Conduit fitting 6pc FIPLOCK SV 45° elbow, black M25x1.5, 7mm, NW23
The one-piece 45°-elbow cable protection conduit fitting AAPA-MMK with a short metric metal thread made of brass nickel plated and specially modified, free-halogen polyamide 6. Due to its excellent UV-resistance for outdoor installations. With the brand new 360° interlocking system and an inside conduit seal, AAPA-MMK complies with the highest possible protection class IP69 in combination with our FIPLOCK® corrugated conduits.
series
AAPA-MMK
Material
Polyamide (PA)
Thread material
Polyamide (PA)
Thread type
Metric
Thread
metrisch
Type of connection
Thread
Construction type
External thread
Revolving thread
No
Model
45°-elbow
Degree of protection (IP)
IP66/IP67/IP68/IP69
Halogen free
Yes
UV-resistant
Yes
Operating temperature
-50...+120 °C
1 Artikel
Item
Nominal diameter mm
Thread connection size
Lowest inner diameter hose mm
Max. outer diameter hose mm
Colour
Thread length mm
Total length mm
Availability
SU
Price / SUexcl. VAT
- Item 880000028Nominal diameter
mm 41.7Thread connection size M25 x 1.5Lowest inner diameter hose
mm 18Max. outer diameter hose
mmColour BlackThread length
mm 7Total length
mm 80.5AvailabilitySU 1 PakPrice / SU excl. VAT
This item is available in 15 other versions.
