Yokis START LIGHT

The Light Start Basic Kit by Urmet provides an efficient solution for controlling your home lighting. This kit allows you to manage up to two lighting zones with on/off functions and an additional dimmable zone, offering flexibility and comfort in lighting management.
Key Features:
Two switching relays: Control two separate lighting circuits with a maximum power of 2000 W per channel.
Dimmer module: Enables smooth brightness adjustment up to 500 W for a personalized lighting atmosphere.
Four-channel transmitter: Allows wireless control of lighting via radio frequency with a range of up to 250 meters in open field.
Easy installation: Modules are designed for installation in standard flush-mounted boxes and require a neutral wire.
Energy-efficient: Low standby power consumption for sustainable operation.
This kit is ideal for retrofitting existing installations or as an introduction to home automation.

1 Version
Yokis BASE Installat.Kit

The Basic Radio System Kit by Urmet provides an efficient solution for controlling shutters and lighting in your home. This kit allows you to manage up to two shutters and two lighting zones, enhancing living comfort and optimizing energy consumption.
Key Features:
Two shutter control modules: Enable precise control of shutters with a maximum power of 500 VA per module.
Two switching relays for lighting: Control two separate lighting circuits with a maximum power of 2000 W per channel.
Four-channel radio transmitter: Offers wireless control of connected devices with a range of up to 250 meters in open field.
Easy installation: Compact modules designed for flush mounting, requiring a neutral wire.
Energy efficiency: Low standby power consumption contributes to sustainable operation.
This kit is ideal for retrofitting existing installations or as an introduction to home automation.

1 Version
Yokis Step Relay Module 500W

The MTR500E flush-mounted time relay by Urmet is an electronic toggle relay that enables the management of lighting or automation systems up to a maximum power of 500 W. With its compact dimensions of 37 x 35 x 12 mm, it is ideal for installation in standard flush-mounted boxes without requiring a neutral wire.
Key Features:
Time Control: Adjustable main timing from 2 seconds to 4 hours, with an additional 1-hour extension and switch-off warning.
Soft Start/Stop Function: Reduces inrush current, extending the lifespan of lamps and pushbuttons.
Electronic Protection: Integrated protection against short circuits and overheating, with automatic reset after fault clearance.
Centralized Management: Ability to centrally control multiple modules via pilot wire using the optional CVI50 accessory.
Versatile Control: Supports control via low voltage pushbuttons (12 or 48 V) with the ADBT adapter.
This module is the ideal solution for retrofitting existing installations or implementing new control systems, especially in environments where a neutral wire is not available.

1 Version
Yokis Dimmer Module

The MTV500E flush-mounted timed dimmer module by Urmet allows seamless brightness adjustment from 3% to 100% for loads up to 500 W. Its compact dimensions of 37 x 35 x 12 mm make it ideal for installation in standard flush-mounted boxes without requiring a neutral wire.
Key Features:
Compatibility: Supports various load types, including dimmable LEDs and halogen lamps.
Memory Function: Remembers the last used brightness level for user convenience.
Timer Function: Adjustable timing from 2 seconds to 4 hours with switch-off warning.
Night Light Mode: Provides gentle illumination that decreases from 20% to a minimal level over an hour, ideal for nighttime navigation.
Soft Start/Stop: Reduces inrush currents, extending the lifespan of lamps and switches.
This module is the perfect solution for upgrading existing lighting systems or implementing new installations, especially in environments where a neutral wire is not available.

1 Version
Yokis Flash Relay Module

The Urmet MTC500E is a flush-mounted electronic flasher relay module designed for controlling lighting up to 500W. This module allows lights to flash at regular intervals, with the flashing frequency adjustable between 0.2 and 25 seconds. It is ideal for applications such as Christmas decorations, pedestrian areas, monuments, and critical safety zones. Thanks to its compact design, it can be easily integrated into existing electrical systems. Key Features:
Adjustable flashing frequency: Allows setting flashing intervals between 0.2 and 25 seconds for flexible applications.
Soft-Start/Soft-Stop function: Reduces inrush current, extends lamp lifespan, and protects switches.
Integrated protection mechanisms: Provides protection against short circuits and overheating with automatic reset after fault resolution.
Centralized control capability: By using the CVI50 accessory (part number 5454805), multiple MTC500E modules can be centrally controlled via a pilot wire.
Easy installation: Can be installed without a neutral wire, facilitating integration into existing systems.

1 Version
Yokis Step Relay Module 500W

The Urmet MTR500M is a timed electronic toggle relay for DIN rail mounting, enabling the management of lighting and automation systems up to 500W. With its flexible timing options and the ability for centralized management via a pilot wire, it offers versatility for modern installations. Key Features:
Flexible timing: Main timing adjustable from 2 seconds to 4 hours, plus an extended timing of 1 hour with switch-off warning.
Centralized management: Multiple MTR500M modules can be managed via a pilot wire using the CVI50 accessory (part number 5454805).
Soft-Start/Soft-Stop function: Reduces inrush current, extends lamp lifespan, and protects switches.
Integrated protection: Provides protection against short circuits and overheating with automatic reset after fault resolution.
Compatibility: Can be operated with low-voltage push buttons (12-48V AC/DC) when used with the ADBT accessory

1 Version
Yokis Dimmer Module

The Urmet MTV500M is a timed 500W dimmer module for DIN rail mounting, enabling smooth dimming without a neutral wire. Key Features:
Dimming range from 3% to 100% for customized lighting
Memory function for last brightness setting
Adjustable timing from 2 seconds to 4 hours
Nightlight mode with soft orientation light
Centralized control via pilot wire with CVI50
Soft-Start/Soft-Stop to protect lamps
Built-in protection against short circuits and overheating
Waterproof, suitable for indoor and outdoor use

1 Version
Yokis Electronic Coil BV40

The Urmet BV40 is an electronic coil specifically designed to ensure module compatibility with illuminated pushbuttons. Its integration allows connecting up to 20 illuminated pushbuttons (maximum 40 mA) into a system, enhancing flexibility and user-friendliness. Key Features:
Enables the use of illuminated pushbuttons: Ensures clear visibility even in dark environments.
Compatibility with up to 20 pushbuttons: Increases flexibility in system design.
Easy integration: Can be seamlessly incorporated into existing systems.
Reliable performance: Ensures system stability even at full load.

1 Version
Yokis Diode D600V

The Urmet D600V is a diode package specifically designed for the centralization of lighting controls and actuators via a pilot wire. Integrating these diodes allows for the isolation of local controls from the rest of the system, enabling more precise and efficient management. Key Features:
Efficient centralization: Allows centralized control of lighting systems via a pilot wire.
Isolation of local controls: Ensures that local commands do not affect the entire system.
Easy integration: Can be seamlessly incorporated into existing systems.
Reliable performance: Ensures stable and consistent functionality.

1 Version
Yokis Interface R12M

The Urmet R12M is a centralization interface that enables the use of double pushbuttons dedicated to light controls or other applications. This interface facilitates the implementation of functions such as on/off and open/close. Key Features:
Centralized control: Allows for centralized management of lighting systems or actuators.
Support for double pushbuttons: Facilitates the implementation of on/off and open/close functions.
Easy integration: Seamlessly integrates into existing systems.
Enhanced efficiency: Optimizes control and increases user-friendliness.

1 Version
Yokis Surge Protector

The Urmet FDVDT surge protection filter is designed to protect modules without a neutral wire (500W range) from surges, especially when dealing with inductive loads such as roller shutters, ferromagnetic ballasts, or transformers. Key Features:
Surge protection: Prevents damage to modules caused by sudden voltage spikes.
Compatibility with inductive loads: Ideal for applications with roller shutters, ferromagnetic ballasts, or transformers.
Easy installation: Can be seamlessly integrated into existing systems to ensure reliable protection.

1 Version
Yokis relay with 230V coil

The Urmet REL1C is an electronic relay with a 230V~ 50Hz coil and a maximum switching current of 0.1A. It provides galvanic isolation and is ideal for centralizing lighting controls in three-phase networks. Its compact design allows for easy integration into existing installations. Key Features:
Galvanic isolation: Ensures safe and reliable separation between control and load circuits.
Easy integration: Compact dimensions facilitate seamless incorporation into existing systems.
Reliable performance: Optimized for use in three-phase systems for efficient lighting management.

1 Version
